- Tech Specs
The pure sine wave inverter provides pure power, with low distortion rate (≤3%), lower power consumption and high conversion efficiency (>85%). Pure sine wave inverters keep voltage and current at safe levels, which is extending the life of appliances. Pure sine wave inverter always makes less noise than modified sine wave inverter.
Using BougeRV solar inverter, user can monitor operating data of applicances in real-time. Let users know the situation of applicance cclearly, which includs: input and output voltage, frequency, battery power, output power wattage, output waveform, inverter working status and other data.
7 multiple protection function: Input low voltage protection, Input over voltage protection, Input overload protection, Short-circuit protection, Over temperature protection, Reverse connection protection. Always monitor and protect circuit safety through LED indicator and alarm sound.
User can controll the inverter via the 3M wired remote controller and can install it in RVs and houses for their need. There are multiple output ports on the BougeRV pure sine wave inverter: a 5V/2.1A USB interface, 3 AC output outlets, a network interface.BougeRV pure sine wave inverter comes with an 2-year warranty that commences from the date of purchase.
With 2 high-speed cooling fans, BougeRV pure sine wave inverter can control temperature intelligently, which will open at high working temperature, and close at nomal temperature.
|Rated power||2000W||Output frequency||60Hz ± 0.5Hz|
|Input voltage||DC 12V||Over voltage shutting||≥16V|
|Rated output voltage||AC 120V ± 10%||Low voltage shutting||≤9.5V|
|Loss when no load||<1.2A||Over temperature shutting||>176℉|
|Output waveform||Pure sine wave||Ambient temperature||14℉ - 113℉|
|Product Dimensions||12.4"L x 8.07"W x 3.54"H||Warranty Description||18 months|
|Input voltage||DC 12V|
|Rated output voltage||AC 120V±10%|
|Output frequency||60Hz ± 0.5%|
|Output waveform||Pure sine wave|
|Rated output efficiency||＞85%|
|Over voltage shutting||≥16V|
|Low voltage shutting||≤9.5V|
|Over temperature shutting||>176℉|
|Operating ambient temperature||-4°F - 140°F|
1.The appliances power shall not be greater than rated power of inverter.
2.The battery should be 12V.
3.Red to positive pole, black to negative pole.
4.This inverter can not be parallel connected.
5.Do not extend the inverter power cable.
No. This inverter can only work with a 12V battery system.
No. The BougeRV DC 12V to AC 120V inverter can only convert DC power to AC power.
Red is for LIVE WIRE.
Green is for EARTH WIRE.
Black is for NEUTRAL WIRE.
